Breakaway Hose Disconnects

Flow Limiters Hose New Nozzles Rebuilt Nozzles Swivels Vapor Recovery
Breakaways are a great way to prevent fuel loss and costly repairs due to drive offs. When a customer leaves the nozzle in their tank and drives off, the breakaway disconnects and stops fuel from leaking out of the hose. We have single use breakaways and reconnectable breakaways. The reconnectable breakaways can be snapped back together. Note: You should always use a whip hose along with a breakaway to ensure that the breakaway will pull straight apart from end to end. Dispensers with a hose retractor should have the breakaway and whip hose attached to the nozzle to ensure that the breakaway will work properly.
catlow_ctm.jpg Catlow Cam Twist 3/4" Magnetic Breakaway SKU: CWCTM75-HD Price: $62.41
Catlow's CAM TWIST Magnetic In-Line Breakaway design is the future of breakaway technology. The CAM TWIST gives you the assurance that your breakaway will perform when you need it most. There is no other breakaway that gives you the option of preventative testing while installed. With a twist the breakaway can be taken apart and inspected for damage, corrosion, and wear without removing the breakaway from service. There will no longer be the need to have a 'remove by date on your breakaway.
The CAM TWIST is designed to be installed between the fuel dispenser and the nozzle. To inspect the unit, two wrenches applied to opposite ends of the breakaway with a twisting motion mechanically separates the unit. The unique design seals the internal components before separation is complete, thus reducing any exposure to product. With the CAM TWIST Magnetic `snap-back technology', alignment and reconnection is easy. After inspection, align the two halves together, and let the magnets do the work while pushing the unit back together.
It's that easy!
catlow_ctm.jpg Catlow Cam Twist 1" Magnetic Breakaway SKU: CWCTM100 Price: $98.14
Catlow's CAM TWIST Magnetic In-Line Breakaway design is the future of breakaway technology. The CAM TWIST gives you the assurance that your breakaway will perform when you need it most. There is no other breakaway that gives you the option of preventative testing while installed. With a twist the breakaway can be taken apart and inspected for damage, corrosion, and wear without removing the breakaway from service. There will no longer be the need to have a 'remove by date on your breakaway.
The CAM TWIST is designed to be installed between the fuel dispenser and the nozzle. To inspect the unit, two wrenches applied to opposite ends of the breakaway with a twisting motion mechanically separates the unit. The unique design seals the internal components before separation is complete, thus reducing any exposure to product. With the CAM TWIST Magnetic `snap-back technology', alignment and reconnection is easy. After inspection, align the two halves together, and let the magnets do the work while pushing the unit back together.
It's that easy!
OPW_66V.jpg OPW 66V Breakaway 3/4" SKU: OP66V-0300 Price: $36.34
The OPW 66 is designed to be installed on fuel dispensing hoses, and will separate when subjected to a designated pull force. The dual valves seat automatically, stopping the flow of fuel and limiting any fuel spillage, while protecting the dispensing equipment.
For proper operation, the OPW 66V-3/4" must always be installed with a straightening hose with a minimum length of 9", such as the OPW 66H. The 66V-1" must be installed with a minimum length of 12" hose.
OPW_66V.jpg OPW 66V Breakaway 1" SKU: OP66V-1300 Price: $83.96
The OPW 66 is designed to be installed on fuel dispensing hoses, and will separate when subjected to a designated pull force. The dual valves seat automatically, stopping the flow of fuel and limiting any fuel spillage, while protecting the dispensing equipment.
For proper operation, the OPW 66V-3/4" must always be installed with a straightening hose with a minimum length of 9", such as the OPW 66H. The 66V-1" must be installed with a minimum length of 12" hose.
HUSKY_2273.jpg Husky 2273 One-Time Safe-T-Break 3/4" SKU: HK2273 Price: $32.70
Features:
  • All Husky Safe-T-Breaks stop the flow of fuel on both sides of the seperation.
  • Unit is lightweight, inexpensive and disposable.
  • Unit Features unusual interface between a pre-loaded spring and a single turn wave spring that enables valve to resist sudden pressure build-up in hose and resultant nuisance seperations.
  • Maximum separation 250 lbs. pull force.
  • U.L. listed
OPW_66REC.jpg OPW 66REC Dry Reconnectable Breakaway 3/4" SKU: OP66REC-1000 Price: $75.71
The OPW 66REC is the first dry reconnectable breakaway for the conventional dispensing market. It is designed to be installed on fuel dispensing hoses, and will separate when subjected to a designated pull force. The dual valves seat automatically, stopping the flow of fuel and limiting any fuel spillage, while protecting the dispensing equipment. When reconnecting the separated halves, the 66REC seals tightly on an O-ring before the poppet stems engage to open the valve.
For proper operation on high-hanging hoses, the OPW 66REC 3/4" must always be installed with a straightening hose with a minimum length of 9" For low hose applications, the OPW 66REC should be installed downstream of the retractor cable.
HUSKY_3360.jpg Husky 3360 Reconnectable Safe-T-Break 3/4" SKU: HK3360 Price: $71.63
Features:
  • All Husky Safe-T-Breaks stop the flow of fuel on both sides of the seperation.
  • Unit Features unusual interface between a pre-loaded spring and a single turn wave spring that enables valve to resist sudden pressure build-up in hose and resultant nuisance seperations.
  • Unit separates at less than 200 lbs. pull force, which minimizes "backlash" force of separation, reducing damage to equipment
  • Model 3360 is reconnectable and retains U.L. listing after reconnection.
  • U.L. listed
HUSKY_2276.jpg Husky 2276 Reconnectable Safe-T-Break 1" SKU: HK2276 Price: $103.67
Features:
  • All Husky Safe-T-Breaks stop the flow of fuel on both sides of the seperation.
  • Internal pressure balancing chamber prevents"line shock" nuisance separation.
  • Unit separates at less than 200 lbs. pull force, which minimizes "backlash" force of separation, reducing damage to equipment
  • Model 2276 is reconnectable and retains U.L. listing after reconnection.
  • U.L. listed
Richards_STTB.jpg OPW 66SB-7575 Breakaway/Swivel - 3/4" x 3/4" Reusable "Re-snap" Breakaway / Swivel SKU: OP66SB-7575 Price: $115.00
FEATURES:
  • 3/4" x 3/4"
  • Replaces Standard Swivel, Breakaway and Spacer Hose
  • Reduces connections (leak point possi- bilities) from five (5) to three (3)
  • Easy Reconnect at Waist Height
  • Installs at the Nozzle Regardless of Dispenser Style
  • Advanced Snap-Back Spring Mechanism .Reusable: Meets ("56711 and retains U.L. & U.L.C. Listing after Recoupling
  • 360" Rotations at Middle Joint and at Male End
  • Double O-rings in Middle Joint and Male End
  • Eliminates Expensive Service Calls while Minimizing Down Time
  • No Repair Kit Needed
Richards_STTB.jpg OPW 66SB-1010 Breakaway/Swivel - 1" Reusable "Re-snap" Breakaway / Swivel SKU: OP66SB-1010 Price: $174.90
FEATURES:
  • 1" x 1"
  • Replaces Standard Swivel, Breakaway and Spacer Hose
  • Reduces connections (leak point possi- bilities) from five (5) to three (3)
  • Easy Reconnect at Waist Height
  • Installs at the Nozzle Regardless of Dispenser Style
  • Advanced Snap-Back Spring Mechanism .Reusable: Meets ("56711 and retains U.L. & U.L.C. Listing after Recoupling
  • 360" Rotations at Middle Joint and at Male End
  • Double O-rings in Middle Joint and Male End
  • Eliminates Expensive Service Calls while Minimizing Down Time
  • No Repair Kit Needed
goodyear_flexsteel.jpg Goodyear 5/8"x 8" Breakaway Whip Hose SKU: GY53232712020869 Price: $15.57
Goodyear 5/8"x 8" 3/4" Male ends Breakaway Whip Hose used between breakaway coupling and dispenser.
goodyear_flexsteel.jpg Goodyear 1"x 10" Breakaway Whip Hose SKU: GY53232713221069 Price: $24.20
Goodyear 1"x 10" Breakaway Whip Hose used between breakaway coupling and dispenser.
